    PZ2100 Series High-Channel Density Precision SMU

    All Your SMU Needs Packed Within a 1U Rack Space

  • Highlights

    All Your SMU Needs Packed Within a 1U Rack Space



    Overcome your test and validation challenges with the PZ2100 source measure unit (SMU) solution. Focus more on characterization and less on synchronization, with multiple SMU module options and up to 20 SMU channels within a 1U rack space. Speed time-to-market with less programming, simplified system integration, and application-specific measurement capabilities.

    • Provides 5x higher channel density than conventional SMUs, offers 20 channels in 1U full-width rack space.
    • Delivers 5 SMU module options and integrated pulser / digitizer for flexible scalability.
    • Offers single-box solution with <50 ns synchronization accuracy on all 20 channels.
    • Provides seamless operation and superior user experience through PathWave IV Curve Measurement software.
    • Supplies user-friendly graphical user interface that collectively manages up to 20 channels maximum.
    • Performs static DC measurements down to 10 fA and pulsed measurements up to 15 MSa/s.
  • broken image

    Flexible Solution for Faster Workflows

    Remove organizational test challenges with the PZ2100 high-channel density precision SMU solution. Meet all your evolving test system requirements with the 5 available SMU module options flexibly configurable and upgradable in the 1U, 4-slot mainframe. Address your application-specific needs with any module combination ranging from high-speed, high-resolution, and high-density SMUs. This flexibility reduces your system bring-up time while removing the need for multiple capital investments for every new project.

  • Key Specifications for PZ2100 Series High-Channel Density Precision SMU

    Number of Channels

    20 Channels / 1U

    Maximum Voltage

    210 V

    Sampling Rate

    15 MSa/s

    Resolution

    10 fA

    Pulse Width

    USB, LAN, optional GPIB

  • Want to see more specifications?

    Download Data Sheet
