- Supports more than 30+ modules (including DC sources, electronic loads, bidirectional power supply, SMU).
- Up to 8 modules can be installed (depends on power), separate control and solation between channels
- Supports master-slave parallel connection between 2 modules to extend power*1
- Graphical operation interface with guided menus, significantly enhancing ease of use
- Supports LIST programming, sequence editing, battery testing/emulating, user-defined waveform and correction scanning, etc
- Built-in EIS (Electrochemical Impedance Spectroscopy) capability (IT2705 with IT27814 SMU module)
- Integrated Ah/Wh statistics, automatically recording regenerative energy
- Flexible display modes: Meter / Scope / Data Logger
- Minimum data logging interval of 20 μs
- Web control supported, allowing full functionality through a standard browser
- Standard interfaces: USB / LAN / CAN / Digital I/O, with free control software PV2700 included

*1 IT27814/IT27814E can be parallel connection only under CC mode.
