Rohde & Schwarz Spectrum Rider FPH handheld spectrum analyzer
- Frequency range from 5 kHz up to 44 GHz
- Tracking generator with frequency range from 30 kHz to 44 GHz (models .23/.36/.54)
- Frequency extensions via keycode
— From 5 kHz down to 100 Hz (applicable to models .06/.13/.26/.23/.36/.44/.54, with R&S®FPH-B29 option installed)
— From 2 GHz to 3 GHz or 4 GHz (model .02)
— From 6 GHz to 8 GHz (model .06)
— From 13.6 GHz to 20 GHz (models .13/.23)
— From 26.5 GHz to 31 GHz (models .26/36)
- Spectrum analysis for e.g.
— Mobile communications
— Radar and satellite communications
— Broadcasting
- Solid RF performance
— DANL: typ. –163 dBm (10 MHz to 3 GHz, preamplifier on)
— TOI measurement: +10 dBm (f = 2.4 GHz)
- Tracking generator with frequency range from 30 kHz to 44 GHz (models .23/.36/.54)
- Frequency extensions via keycode
— From 5 kHz down to 100 Hz (applicable to models .06/.13/.26/.23/.36/.44/.54, with R&S®FPH-B29 option installed)
— From 2 GHz to 3 GHz or 4 GHz (model .02)
— From 6 GHz to 8 GHz (model .06)
— From 13.6 GHz to 20 GHz (models .13/.23)
— From 26.5 GHz to 31 GHz (models .26/36)
- Spectrum analysis for e.g.
— Mobile communications
— Radar and satellite communications
— Broadcasting
- Solid RF performance
— DANL: typ. –163 dBm (10 MHz to 3 GHz, preamplifier on)
— TOI measurement: +10 dBm (f = 2.4 GHz)
